True ALPINE RUNNER - Page 18

Truetness.com / 800.426.6570 / 636.272.7100
CHAPTER 2: ASSEMBLY GUIDE
18 of 50
ASSEMBLY STEPS:
Step 9 Lower Console Rack Cover:
Step 10 Outer Console Rack Covers:
a) Install the lower console rack cover
using 13 screws, but do not tighten
completely until all screws are installed.
Hardware Required:
13 M4xP0.7x12mm Screws
a) Attach the Outer Console Rack
Covers using four screws for each cover.
Hardware Required:
8 M4xP0.7x12mm Screws
