CHAPTER 2: ASSEMBLY GUIDE
22 of 50
ASSEMBLY STEPS:
Step 14 Remove Middle Frame Cover:
Step 15 Select Voltage:
a) Determine if the unit is being installed on
a 110 volt line or a 220 volt line.
b) For 110V units, skip to Step 19. For 220V
units, proceed with Step 15.
c) Remove the middle frame cover by
removing the 4 screws as shown.
d) Set the screws aside for use in step 17.
a) For all 220V outlets, ip the selector
switch up.
