CHAPTER 2: ASSEMBLY GUIDE
Truetness.com / 800.426.6570 / 636.272.7100 23 of 50
ASSEMBLY STEPS:
a) Remove M5 x 10mm bolt from the power inlet plate on
the machine.
b) Install the retaining plate using the spacer and M5 x
60mm bolt.
c) Insert the power cord into the power inlet plate.
d) Swing retaining plate around power cord and reinsert
the M5 x 10mm bolt.
c) Plug the unit into a power source and turn on the power
switch.
d) Aer the running surface lis into a level positon, turn
the unit o and proceed to the next step.
Hardware Required:
1 Retainer Plate 1 Spacer
1 M5xP0.8x60mm 1 M5xP0.8x10mm
Step 16 Reinstall Middle Frame Cover:
Step 17 Connect Power:
a) Re-install the Middle Frame Cover to the
front of the unit using 4 screws.
Hardware Required:
Screws from Step 15
