Attaching the Safety Guard
1. Loosen the bolts with the hex key 4 mm and remove
them together with the washers, spring washer and nuts.
2. Move the retainer downward. If required, slightly loosen
the hex bolt.
3. Place the safety guard between retainer and support and
move the retainer upward.
4. Secure the safety guard with the mounting sets.
Figure 15 Attaching the Safety Guard
