Maintaining the Bevel Gear
The bevel gear is filled with grease. Regularly check the quantity
and fill up using proper grease if necessary.
Loosen the screw with the hex key 5 mm (41) and remove
it together with the washer.
Add suitable lubricant.
Refit the washer and screw. Ensure the screw is properly
tightened.
Figure 51 The Bevel Gear
Figure 52 Greasing The Bevel Gear
