Truma DLE60C Operating And Installation Instructions

15
AquaGo technical data
BTU/h
(Nominal input rate)
20,000 – 60,000
Fuel LP gas (propane
only)
Fuel inlet pressure 10.5 – 14 in. wc
(26.2 – 34.9 mbar)
Fuel manifold pressure 1.3 – 10 in wc
(3.2 – 24.9 mbar)
Nominal voltage 12 V DC (<1V
pp
)
Power input
AquaGo basic < 1.5 A
AquaGo comfort < 2.5 A
AquaGo comfort plus < 2.5 A
Water operating pressure 65 psi (4.5 bar)
max.
Standard water outlet
temperature
120°F (49°C)
Water volume 0.35 gallons
(1.3liter)
Ambient temperature
AquaGo basic +32°F…+104°F
(+5°C…+40°C)
AquaGo comfort
AquaGo comfort plus
-4°F…+104°F
(-20°C…+40°C)
Dimensions (without flange and frame)
Width Height Depth
in. 12.5 12.5 15.5
mm 318 318 394
Dimensions of frame
Size XS
in. 15.1 15.5 0.8
mm 384 394 20.2
Standard
in. 17.7 17.7 0.8
mm 450 450 20.2
Adapter
in. 20.1 20.1 0.8
mm 510 510 20.2
Installation cutout and depth
Width Height Depth*
in. 12.8 12.8 17.7
>19.7**
mm 324 324 450
>500**
Weight of unit without
access door
(approx.)
34.2 lbs (15.5 kg)
Weight of access door stan-
dard and access door XS
(approx.)
2.9 lbs (1.3 kg)
Weight of access door
adapter kit
(approx.)
5.5 lbs (2.5 kg)
* Depending on application
** Recommended
Maintenance
Repairs must be performed by a certified ser-
vice technician. Truma recommends that the
appliance be serviced annually by a certified
service technician. Verify proper operation after
servicing.
High temperatures or repair attempts
while the gas supply is turned on may
result in scalding injuries!
• Turn OFF the electrical power supply and
the LP gas supply before starting mainte-
nance and repair work.
• Allow the appliance to cool down.
• Never actuate the pressure relief valve as
long as the appliance is still hot.
Injuries caused by the Easy Drain Lever!
• Never actuate the Easy Drain Lever as long
as the appliance is under water pressure
and/or is still hot.
Sharp edges can cause cuts and injury!
• Always wear protective gloves to avoid
injuries from sharp edges during mainte-
nance work.
Draining the water and cleaning the
water inlet filter
To keep the appliance fully functional, clean
the water inlet filter at least once a year.
1. AquaGo comfort / AquaGo comfort plus
Set the control panel to “Off”.
2. Remove the access door (refer to “Removing
the access door” on page9).
3. Switch OFF the appliance at the POWER
switch.
4. Open all hot water faucets and wait for cold
water. This will ensure that hot water is re-
moved from the appliance before draining.
5. Turn OFF the water supply or switch OFF the
water pump.
