Truma DuoControl - Low-Pressure Section

DuoControlTechnical data
54 EN
50020-00984 ∙ 00 ∙ 08/2022
9 Technical data
(determined in accordance with EN 16129:2013 or Truma test condi-
tions)
Size Value
Gas type Liquid gas (propane / butane)
Inlet pressure 0�7–16bar
Output pressure 30mbar
Regulator capacity 1�5kg/h
Regulator inlet Male thread M20 x 1�5 (G�13)
M20x1�5 union nut tight-
ening torque
3–5Nm
Regulator outlet
Olive screw connection 8 mm or 10
mm (H�9)
8mm cutting ring screw
connection tightening torque
14–19Nm
10mm cutting ring screw
connection tightening torque
16–21Nm
Operating temperature -20°C to +50°C
Weight 900 g
Product ID number CE-0085CT0438
PIN: CE-0085CT0438 PIN: UKCA 740586
XX: Year of manufacture, printed on the type plate�
