TSC MH341T Series User Manual

3
Power
Internal switching power supply
 Input: AC 100-240V, 4-2A, 50-60Hz
 Output: DC 5V, 5A; DC 24V, 7A; DC 36V, 1.4A; Total 243W
LCD display/
Operation
buttons
 6 operation buttons (menu,
feed/pause, up, down, left, right)
 1 LED (with 2 LEDs Green & Red)
 Multi-language selectable
 6 operation buttons (menu, select, up, down, left/pause, right/feed)
 1 LED (with 2 LEDs Green & Red)
LCD
 3.5” color display, 320 x 240 pixel
 4.3” color display , 480 x 272 pixel; Resistive touch screen
Sensors
 Gap transmissive sensor (position
adjustable)
 Black mark reflective sensor
(Bottom or Top black mark sensor
switchable and position
adjustable)
 Head open sensor
 Ribbon encoder sensor
 Ribbon end sensor
 Gap transmissive sensor (position adjustable)
 Black mark reflective sensor(Bottom or Top black mark sensor switchable and
position adjustable)
 Head open sensor
 Ribbon encoder sensor
 Ribbon end sensor
 Media near end sensor
Real time
clock
 Standard
Internal font
 8 alpha-numeric bitmap fonts
 One Monotype Imaging® CG Triumvirate Bold Condensed scalable font
 Built-in Monotype True Type Font engine
Bar code
1D bar code
Code 39, Code 93, Code128UCC, Code128 subsets A.B.C, Codabar, Interleave 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E,
EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, RSS-Stacked, GS1 DataBar, Code 11, China Post
2D bar code
PDF-417, Maxicode, DataMatrix, QR code, Aztec
Font & bar
code rotation
0, 90, 180, 270 degree
Print language
TSPL-EZD (Compatible to EPL, ZPL, ZPL II, DPL)
Media type
Continuous, die-cut, black mark (Bottom side or top side black mark), fan-fold, notch, perforated, tag, care label (outside
wound)
Media width
20 ~ 114 mm (0.79" ~ 4.5")
Media
thickness
0.06 ~ 0.28 mm (2.36 ~ 11 mil)
Media core
diameter
3.81mm/76.2mm (1.5”/ 3” )
Label length
5 ~ 25,400 mm (0.20” ~ 1,000”)
5 ~ 11,430 mm (0.20” ~ 450”)
5 ~ 2,540 mm (0.20” ~ 100”)
Environment
condition
Operation: 0 ~ 40˚C ( 32 ~ 104˚F), 25~85% non-condensing
Storage: -40 ~ 60 ˚C (-40 ~ 140˚F), 10~90% non-condensing
Safety
regulation
FCC Class A, CE Class A, RCM Class A, UL, cUL, TÜV/safety, CCC, KC, BIS, ENERGY STAR®
