6. Adjust the label guide to fix the media
position.
Note:
* Please install the media through
the media sensor.
* The sensor location is marked by a
triangle mark ▽ (gap sensor) and
arrow mark↓(black mark sensor) at
the sensor housing.
* The media sensor position is
movable, please make sure the gap
or black mark is at the location
where media gap/black mark will
pass through for sensing.
7. Close the print head mechanism on
both sides and make sure the latches
are engaged securely.
8. Set media sensor type and calibrate
the selected sensor.
Note:
* Please calibrate the gap/black mark
sensor when changing media.
* Please refer to video on TSC
YouTube.
