TSC MX341P Series User Manual

- 3 -
Bar code
1D bar code
Code 39, Code 93, Code128UCC, Code128 subsets A.B.C, Codabar, Interleave 2 of 5,
EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI,
PLESSEY, POSTNET, RSS-Stacked, GS1 DataBar, Code 11, China Post
2D bar code
PDF-417, Maxicode, DataMatrix, QR code, Aztec
Font & bar code rotation
0, 90, 180, 270 degree
Printer language
TSPL-EZD (Compatible to EPL, ZPL, ZPL II, DPL)
Media type
Continuous, die-cut, black mark (Bottom side or top side black mark), fan-fold, notch,
perforated, tag, care label (outside wound)
Media width
20 mm ~ 114 mm (0.78“ ~ 4.49“)
Media thickness
0.076 ~ 0.305 mm (2.99 ~ 12.01 mil)
Media core diameter
76.2 mm (3”)
Label length
3 ~ 25,400 mm (0.1“ ~
1,000“) ,
3 ~ 11,430 mm (0.1“ ~ 450“),
3 ~ 2,540 mm (0.1“ ~ 100“)
Environment condition
Operation: 0~ 40˚C (32 ~ 104˚F), 25~85% non-condensing
Storage: -40 ~ 60 ˚C (-40 ~ 140˚F), 10~90% non-condensing
Safety regulation
BIS、CB、CCC、CE Class B、EAC、FCC Class B、KC、TUV、UL、cUL、C-Tick Class B
、Energy Star
Environmental concern
Comply with RoHS, WEEE
Accessories
 Windows labeling software CD disk
 Quick start guide
 USB port cable
 Power cord
Factory option
 Internal full rewinding kit ( Max. 8“ OD )
 Internal Bluetooth 5.0 MFi
Dealer option
 Peel off module assembly
 Regular guillotine cutter
 Rotary heavy duty cutter
 GPIO (DB15F)+ Parallel interface
User option
 KP-200 Plus keyboard display unit
 802.11 a/b/g/n/ac Wi-Fi + BT combo module
 Universal cutter tray

TSC MX341P Series Specifications

General

Brand	TSC
Model	MX341P Series
Category	Barcode Reader
Language	English
