1.2 Product Specification and Features
Printer model
MX241P
MX341P
MX641P
Resolution
8 dots/mm (203 DPI)
12 dots/mm (300 DPI)
24 dots/mm (600 DPI)
Printing method
Thermal transfer and direct thermal
Print speed
457mm (18”)/second
356 mm (14”)/second
152 mm (6”)/second
Max. print width
104 mm(4.09”)
Max. print length
25,400 mm (1000”)
11,430 mm (450”)
2540 mm (100”)
Enclosure
Die-cast print mechanism with large clear media view window
Physical dimension
300 mm (W) x 393 mm (H) x 510 mm (D)
11.81“ (W) x 15.47“ (H) x 20.08“ (D)
Weight
18 kg (39.68 lbs)
Label roll capacity
203.2 mm (8“) O.D.
Ribbon
600 meter long, max. OD 90 mm,1“ core (ink coated outside/inside)
Ribbon width
25.4 ~ 114.3 mm (1”~4.5”)
Processor
32-bit RISC CPU
Memory
 512 MB Flash memory
 512 MB SDRAM
 microSD Flash memory card reader for Flash memory expansion, up to 32 GB
Interface
 RS-232
 USB 2.0
 Internal Ethernet, 10/100 Mbps
 USB host *2 (Front side), for scanner or PC keyboard
 GPIO + Centronics (dealer option)
 Internal Bluetooth MFi 5.0 (factory option)
 802.11 a/b/g/n/ac Wi-Fi + BT combo module (user option)
Power
 Internal universal switching power supply
 • Input: AC 100-240V, 4-2A, 50-60Hz
 • Output: DC 5V, 5A; DC 24V, 7A; DC 36V, 1.4A; Total 243W
LCD
 16 bits Color, 480 x 272 pixel, with back light, Resistive Touch Screen
Operation switch, button Select
1 power switch, 6 operation buttons (Menu, Pause, Feed, Up, Down, Select)
Sensors
 Gap transmissive sensor (position adjustable)
 Black mark reflective sensor(Bottom or Top black mark sensor switchable and
position adjustable)Ribbon end sensor (transmissive)
 Head open sensor
 Ribbon end sensor
 Ribbon encode sensor
 Media capacity sensor
Real time clock
Standard
Internal font
 8 alpha-numeric bitmap fonts
 One Monotype Imaging® CG Triumvirate Bold Condensed scalable font
 Built-in Monotype True Type Font engine
