- 44 -
Use this item to setup printing darkness. The available
setting range is from 0 to 30. You may need to adjust
your density based on selected media.
Use this item to setup print speed. Available setting
range is 2~18 for 203dpi, 2~14 for 300dpi and 1.5 ~6 for
600dpi.
203 dpi: 6
300 dpi: 4
600 dpi: 3
Use this item to setup feed speed. Setting value is up to
8 ips.
203 dpi: 6
ips
300 dpi: 4
ips
600 dpi: 3
ips
Use this item to setup back feed speed. Setting value is
up to 6 ips.
This item is used to fine tune media stop location.
Available setting value range is from -120~120 dots.
This item is used to set the print mode. There are 3
modes as below,
Next label top of form is aligned to the print
head burn line location.
Enable the label peel off mode.
Enable the label cutter mode
Enable the label rewind mode
The print engine prints a label when it
receives a signal from the applicator.
This item is used to set print width. The available value
range is 2 ~ 999 dots.
This feature is used to print current printer available fonts
list to the label. The fonts stored in the printer’s DRAM,
Flash or optional memory card.
This feature is used to print current printer available
images list to the label. The images stored in the
printer’s DRAM, Flash or optional memory card.
This feature is used to print current printer available
formats list to the label. The formats stored in the
printer’s DRAM, Flash or optional memory card.
This feature is used to print current printer configuration
to the label.
This feature is used to set control prefix character.
This feature is used to set format prefix character.
This feature is used to set delimiter character.
