TSC Printronix MB240 Series User Manual

24
5. Thread the media under the damper assembly, through the media sensor and under the printhead. Keep feeding the media
until the media extends out of the front side of the cutter.
6. Align the media with the media guide ensuring that the
media is threaded under the guide.
7. Adjust the media guide ensuring that the location of the
guide fits with the media’s width.
Damper Assembly
Media Sensor
Printhead

TSC Printronix MB240 Series Specifications

General

Type	Industrial Barcode Printer
Resolution	203 dpi (8 dots/mm)
Media Type	Direct Thermal, Thermal Transfer
Communication Interface	USB, Serial, Ethernet
Interface	USB 2.0, RS-232, Parallel, Ethernet 10/100
Supported Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-8, EAN-13, Interleaved 2 of 5, Codabar, PDF417, QR Code, Data Matrix
Scanning Method	Thermal Transfer/Direct Thermal
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
