TSC TC300 Series User Manual

TC200/ TC300/ TC210/ TC310
Bar Code Printer Service Manual
18
3.4 Replacing the Platen Roller Assembly
1. Open the printer top cover to
remove the front panel.
2. Disengage the platen holder tabs to the lower inner cover by pulling out the right side
and left side tabs toward the center of platen and rotates 90 degrees.
3. Take out the platen roller assembly
and replace a new platen roller
assembly.
4. Reassemble the parts in the
reverse procedures.
