TTP-246M PRO SERIES – Industrial Thermal Transfer Bar
Code Printer
PRINTER MODEL TTP-246M Pro TTP-344M Pro
Resolution 8 dots/mm (203 DPI) 12 dots/mm (300 DPI)
Printing method Thermal Transfer & Direct Thermal
Max. print speed 203 mm (8”)/second 152 mm (6”)/second
Max. print width 108 mm (4.25”) 104 mm (4.09”)
Max. print length 2,286 mm (90”) 1,016 mm (40”)
Enclosure Die-cast aluminum base and frame/Metal cover with large clear media view window
Physical dimension
270 mm (W) x 308 mm (H) x 505 mm (D)
10.63” (W) x 12.13” (H) x 19.88” (D)
Weight 15 kg (33.07 lbs)
Label roll capacity 208.3 mm (8.2” ) OD
Ribbon 600 m long, max. OD 90 mm, 1” core (ink coated outside or inside)
Ribbon width 25.4 mm ~ 114.3 mm (1” ~ 4.5”)
Processor 32-bit RISC CPU
Memory
• 4 MB Flash memory
• 8 MB SDRAM
• SD Flash memory card reader for Flash memory expansion, up to 4 GB (dealer option)
Interface
• RS-232
• Centronics
• USB 2.0
• USB host, for scanner or PC keyboard (factory option)
• PS/2 keyboard (dealer option)
• Internal Ethernet, 10/100 Mbps (dealer option)
• GPIO (dealer option)
• Bluetooth (user option)
Power
Internal switching power supply
• Input: AC 100-240V, 3A, 50-60Hz
• Output: DC 24V, 3.3A, 80W
LCD Graphic type, 128 x 64 pixel, with back light
Operation switch, button 1 power switch, 6 operation buttons (Menu, Pause, Feed, Up, Down, Select) & 3 LEDs
Sensors
• Gap transmissive sensor (position adjustable)
• Black mark reflective sensor (position adjustable)
• Head open sensor
• Ribbon end sensor
Real time clock Standard
Internal fonts
• 8 alpha-numeric bitmap fonts
• Monotype Imaging
®
true type font engine with one CG Triumvirate Bold Condensed scalable font
Bar code
• 1D bar code
Code 39, Code 93, Code 128UCC, Code 128 subsets A.B.C, Codabar, Interleave 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A,
UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST, GS1 DataBar, Logmars
• 2D bar code
PDF-417, Maxicode, DataMatrix, QR code, Aztech
Font and barcode rotation 0, 90, 180, 270 degree
Printer language TSPL-EZ
TM
(Compatible to EPL, ZPL, ZPL II)
Media type Continuous, die-cut, fan-fold, tag, notched, black mark, perforated, care label (outside wound)
Media width 25.4 ~ 118 mm (1" ~ 4.6")
Media thickness 0.06 ~ 0.30 mm (2.36 ~ 11.81 mil)
Media core diameter 25.4 ~ 76.2 mm (1” ~ 3”)
Label length 5 ~ 2,286 mm (0.20” ~ 90”) 5 ~ 1,016 mm (0.20” ~ 40”)
Environment condition
Operation: 5 ~ 40°C, 20 ~ 85% non-condensing
Storage: -40 ~ 60°C, 5 ~ 90% non-condensing
Safety regulation FCC Class A, CE Class A, C-Tick Class A, UL, CUL, TÜV/Safety, CCC, CB
Environmental concern Comply with RoHS, WEEE
Accessories
• Windows labeling software CD disk
• Quick start guide
• USB cable
• Power cord
Limited warranty
• Printer: 2 years
• Print head: 25 km (1 million inches) or 12 months which comes first
• Platen: 50 km (2 million inches) or 12 months which comes first
Factory options N/A
Dealer options
• Internal rewinding kit
• Peel-off kit
Multi-interface board:
• Configuration 1: Internal Ethernet interface (10/100 Mbps) + PS/2 keyboard interface + SD Flash memory card reader
• Configuration 2: USB host + Internal Ethernet interface (10/100 Mbps) + PS/2 keyboard interface + SD Flash memory card reader
• Configuration 3: GPIO interface + USB host + Internal Ethernet interface (10/100 Mbps) + PS/2 keyboard interface + SD Flash
memory card reader
User options
• Bluetooth module (serial interface)
• Regular cutter (full cut guillotine cutter)
• Heavy duty cutter (rotary cutter)
• Care label cutter (rotary cutter)
• KP-200 Plus series keyboard
• KU-007 Plus programmable smart keyboard
TSC
®
is a trademark of TSC Auto ID Technology Co., Ltd.
TSC Auto ID Technology Co., Ltd. is an ISO 9001/14001 registered company.
© 2016 TSC Auto ID Technology Co., Ltd.
Product models and Specifications are subject to change without notice.
Contact your TSC sales representative for specific information.
