Instrument Operation 4-7
Liquid Level
Full is indicated if adequate butanol is present in the liquid reservoir as
detected by the internal reservoir liquid level sensor. If the liquid level is
low, Not Full is indicated.
Laser Current
Laser power is monitored by an internal detector in the laser diode
package, and displayed.
Device Details
Additional details associated with the device are displayed.
Data M a n agement S c r een
The Data Management screen is used to manage the data stored in the
internal memory. After selecting one or all of the stored files using the
check boxes on the left of the screen:
Press the Export button to export the file(s) to a USB flash drive
connected to a USB A port on the back of the CPC.
or
Press the Delete button to delete the selected file(s).
Figure 4-5
CPC Data Management Screen
