Specifications A-3
Table A-1
Model 3776 CPC Specifications
Physical features
Front panel .........................
Back panel..........................
Side panel...........................
LCD TFT QVGA (320 ×240 pixel) 5.7-inch color display,
aerosol inlet, LED particle indicator light, rotate/select
control knob, flash memory card slot
Power connector, USB, Ethernet, two 9-pin D-sub serial
connectors, two BNC inputs, two BNC outputs, fan,
butanol-fill connector, butanol-drain connector, makeup-
air port, pump-exhaust port, fill bottle and bracket
Butanol-level viewing window
Dimensions (HWD)
(nominal) ...........................
25 cm × 32 cm × 37 cm (10 in. × 13 in. × 15 in.), not
including fill bottle and bracket
Weight ................................. 9.9 kg (22 lb)
Fuse ..................................... 2-~ F 6.3A FB/250V (internal –not replaceable by operator)
