2-1
CHAPTER 2
Unpacking and Setting
up the CPC
Use the information in this chapter to unpack the Model 3775
Condensation Particle Counter (CPC) and set it up.
Packing List
Table 2-1 shows the components shipped with the Model 3775
CPC.
Table 2-1
Model 3775 CPC Packing List
Qty. Description
1 Model 3775 and Operation Manual
1 Power Cable
1 Aerosol Instrument Manager
®
Software
1 Fill Bottle
1 Drain Bottle
1 Bottle Bracket
1 RS-232 Cable (9-pin M/F, 12 ft)
1 USB I/O Cable A/B 6 ft
1 SanDisk ImageMate 5-in-1 Card Reader
1 Data Memory Card
1 Saturator Wick for CPC 3775
1 Orifice, Critical Flow (
1
⁄8”NPT x
1
⁄8” barb)
2 Variable Orifice, Bypass and Makeup Air (Ftg NY RSTR 0-0.025)
2 Insulation Plug .50 dia × .50 thk
2 Insulation Plug .75 dia × .50 thk
1 Filter, Charcoal
1 SS Elbow Fitting for Mounting Charcoal Filter
2 Micro Pump Filter (Filter Inline, 25 micron)
3 Fill/Drain/Makeup Air Filter (Filter Inline, 73 micron)
1 Bypass Air/Exhaust Filter (Filter, inline NY .6 um)
1 O-Ring for Reservoir Cover (FSI Ring 1-030)
1 Checkout Data Sheet
1 Certificate of Conformance
Note: Some items above and those for future maintenance are
available for purchase as kits from TSI. A complete list of
replacement part kits is included in the maintenance section in
Chapter 8.
