TTI QL355 - Ql564

QL564
Step/Range Settings Adjust for:- Load Detail
1, 56V 2A 0.01V 2A 10mV ± 0.5mV DVM o/p 0V
2, 56V 2A 0.01V 2A 0.010V on display DVM V readback zero
3, 56V 2A 35V 2A 35V ± 0.5mV DVM o/p V span
4, 56V 2A 35V 2A 35.000 on display DVM V readback span
5, 56V 2A 41V 2A 41.000 on display DVM V readback 13bit
6, 56V 2A 0.01V 2A 10mV ± 0.5mV DVM o/p 0V
7, 56V 2A 35V 2A 35V ± 0.5mV DVM o/p V span
8, 56V 2A 2V 0.001A 1mA ± 0.5mA milli-ammeter o/p A offset
9, 56V 2A 2V 0.001A 0.001 on display milli-ammeter A readback zero
10, 56V 500mA 2V 0.1mA 0.1mA ± 0.05mA milli-ammeter o/p mA offset
11, 56V 500mA 2V 0.1mA flashing 0.0/0.1 on display milli-ammeter mA readback zero
change load
12, 25V 4A 2V 4A 4A ± 0.5mA ammeter o/p A span
13, 25V 4A 2V 4A 4.000 on display ammeter A readback span
14, 56V 500mA 2V 400mA 400mA ± 0.05mA ammeter o/p mA span
15, 56V 500mA 2V 400mA 400.0 on display ammeter mA readback span
16, 56V 500mA 2V 410mA 410.0 on display ammeter mA readback 13bit
12
