PCB ASSEMBLY – POWER – QL355 (44117-0010) continued/…
Part Number Description Position
25377-5490 TRAN NPN BC549C Q1, 2, 10-12,18, 24
25381-0404 TRAN NPN 2N3904 Q17,21
25383-0505 TRAN NPN BC338 Q23
25386-9300 TRAN NPN TIP31A Q22
25601-0590 TRAN MOSFET N CHAN HUF75639G3 Q15,16
27001-0020 OPTO-COUPLER CNY17-3 IC44, 52
27001-0050 OPTO-COUPLER 6N136 IC48, 49
27001-0110 OPTO-COUPLED TRIAC 3011 IC4, 5
27103-0003 IC LM393 IC6, 50
27160-0009 IC V/REG 7805 IC3
27160-0014 IC V/REG 7905 IC2
27160-0200 IC V/REG LM317 IC1
27164-0507 IC ULN-2003A IC38
27226-0210 IC 4021B IC34, 35, 41
27226-0940 IC 4094B IC28
27231-0000 IC 74HC00 IC8
27231-0140 IC 74HC14 IC7
27231-5740 IC 74HC574 IC32, 33
27250-1970 IC MCU PIC16F76 IC39
27401-0060 IC 24LC04BP (512x8) EEPROM IC31
28151-0010 BUZZER BUZZ1
28500-1160 XTAL – 9.8304MHz – MICRPROCSR XTL1
35555-3290 PCB – POWER
PCB ASSEMBLY – POWER – QL564 (44117-0100)
Part Number Description Position
20073-9801 SCREW No.4x1/4in. Plastite HEATSINK FIXING
20613-0026 SIL-PAD 900S 100MM X 25MM FOR SK1, 2
20661-0290 SPACER Clr No.4 X 22.2mm Nylon POWER PCB TO COVER
20670-0360 HEATSINK MAXS515 100MM PLAIN SK1, 2
20670-0364 CLIP MAX01H FOR TO220+MAX H/S FOR IC1-3, Q22, SCR1, 2
20670-0365 CLIP MAX03H FOR TO247+MAX H/S FOR BR1, Q15, Q16
22240-0150 RELAY 12V DPDT 8A RL1, 2
22312-0242 FUSE CLIPS PCB MTG FS1
22315-0248 FUSE 10A ANTISURGE (T) HBC CER FS1
22315-0452 FUSE 1.0AT SUBMIN PCB MTG FS4-6
22573-0041 HEADER2WAY STR SIL TP1, LK1, LK2
15
To Next Page
