PCB ASSEMBLY – POWER – QL564 (44117-0100) continued/…
Part Number Description Position
23301-0468 RES NETWK SIL 22K X 5 RP3
23424-0443 CAP10NZ 1KV CER D10 P5 C12,13
23428-0100 CAP10PG 100V CER NPO P2.5T C56, 57
23557-0500 CAP 1U0 50V ELEC P1.5 C86, 88
23557-0647 CAP 10U 35V ELEC P2 C6-8, 43
23557-0660 CAP 2200U 16V ELEC P5 C3
23557-0664 CAP 1000U 35V ELEC P5 C1,2
23557-0672 CAP 470U 10V ELEC P3.5 C71
23557-0673 CAP 22U 35V ELEC P2 C14
23557-0775 CAP 4700U 100V ELEC P10 C4,5
23620-0246 CAP 100NK 63V P/E P5 C15,18-20, 55, 61, 64, 67-70, 95,96
23620-0247 CAP 220NK 63V P/E P5 C16,17
23620-0257 CAP 2U2K 100V P/E P22.5 C9,10
23620-0263 CAP 220NK 250V P/E P15 C11, 23
23620-9007 CAP 10NK 100V P/E P5 C87
25021-0901 DIO 1N4148 B/R D1-7, 24
25115-0907 DIO 1N4002 B/R D20, 21
25210-0060 THYRISTOR 2N6507 SCR1, 2
25211-0303 RECTIFIER BRIDGE 8A 200V SIL BR1
25211-9302 RECTIFIER BRIDGE W02G BR2, 3
25336-5590 TRAN PNP BC559C Q5-9, 26
25341-0218 TRAN PNP 2N3906 T Q13,14
25377-5490 TRAN NPN BC549C Q1, 2,10-12,18, 24
25381-0404 TRAN NPN 2N3904 T Q17,21
25383-0505 TRAN NPN BC338 Q23
25386-9300 TRAN NPN TIP31A Q22
25601-0710 TRAN MOSFET N CHAN STW60NE10 Q15,16
27001-0020 OPTO-COUPLER CNY17-3 IC44, 52
27001-0050 OPTO-COUPLER 6N136 IC48, 49
27001-0110 OPTO-COUPLED TRIAC 3011 IC4,5
27103-0003 IC LM393 IC6, 50
27160-0009 IC V/REG 7805 IC3
27160-0014 IC V/REG 7905 IC2
27160-0200 IC V/REG LM317 IC1
27164-0507 IC ULN-2003A IC38
27226-0210 IC 4021B IC34, 35, 41
17
