TTI QL355 - Page 20

PCB ASSEMBLY – CONTROL (44117-0020) continued/…
Part Number Description Position
23215-3130 RES 13K0B W25 MF 15PPM R61
23215-4150 RES 150KB W25 MF 15PPM R64, 65
23284-0110 RES 0R51J 2W5 WW R51
23286-0040 RES 0R05J 15W WW ALUM HSD R50
23385-2220 RES PS/H 2K2 CF 6MM VR1, 2
23427-0388 CAP 220PK 100V CER P2.5 C81
23427-0388 CAP 220PK 100V CER P2.5 C49
23427-9205 CAP 47PJ 100V CER NPO P2.5 C44-48, 62, 72, 74-78
23428-0100 CAP 10PG 100V CER NPO P2.5T C37
23557-0500 CAP 1U0 50V ELEC P1.5 C42
23557-0647 CAP 10U 35V ELEC P2 C24, 25, 27, 53, 58, 60
23557-0694 CAP 220U 100V ELEC P5 C40,41
23620-0246 CAP 100NK 63V P/E P5 C22, 23, 26, 28, 30, 33, 35, 36, 39, 54, 59,
65, 66, 79, 80, 82
23620-0247 CAP 220NK 63V P/E P5 C63
23620-0249 CAP 330NK 63V P/E P5 C31, 32, 34
23620-0252 CAP 2N2K 63V P/E P5 C50, 56, 61
23620-0286 CAP 470NF 100V P/E P5 C92, 93
23620-9007 CAP 10NK 100V P/E P5 C51, 52, 55, 57, 84
25021-0901 DIO 1N4148 B/R D9, 10, 15-19
25031-0040 DIO BAX16 D13, 14
25334-0011 TRAN PNP TIP30 Q18
25336-5590 TRAN PNP BC559C Q9
25341-0218 TRAN PNP 2N3906 Q25
25377-5490 TRAN NPN BC549C Q4, 5
25383-0610 TRAN NPN ZTX653 Q19, 20
25601-0620 TRAN MOSFET N CHAN LL Q3
27103-1040 IC SM LM393 IC17, 26
27106-0644 IC SM TL074CD BI-FET OP AMP IC15
27106-0645 IC SM TO072CD DUAL BIFET OP AMP IC31, 32
27106-1080 IC SM OP07CS IC22
27106-1240 IC SM MCP602 IC28
27106-1250 IC SM MCP602 OP AMP IC28
27153-1120 IC SM MCP3201B 12 BIT ADC IC37
27161-0061 IC V/REF AD680 T092 IC16
27162-1030 IC SM MAX5441 ACUA 16 BIT DAC IC1
