PCB ASSSEMBLY - GPIB INTERFACE (44117-0030) continued/…
Part Number Description Position
23557-0657 CAP 100U 10V ELEC RE2 P2 C5-7
23557-0689 CAP 3300U 16V ELEC RE3 P5 C20-21
23595-0010 CAP SM-A 1U0M 16V TANT C14
25211-9302 RECTIFIER BRIDGE W02G BR1
25377-1000 TRAN SM NPN BC849C Q1-2
27160-0440 IC V/REG LM2940CT5 IC4
27161-2020 IC SM ZSM560 SUPPLY VOLTS MON IC14
27162-0010 IC 7660 IC5
27163-1600 IC 75160 IC11
27163-1610 IC 75161 IC10
27236-0530 IC SM 74HC4053 IC16
27239-0000 IC SM 74HC00 IC12
27239-0140 IC SM 74HC14 IC3
27239-0320 IC SM 74HC32 IC13
27250-0410 IC UPD7210C GPIB CONT IC9
27250-0510 IC SM FT8U232AM IC17
27253-0020 IC SM 64180 IC6
27253-0050 IC SM 14C88 IC1
27253-0060 IC SM 14C89 IC2
27400-0100 IC 27C512 64Kx8 EPRM 200ns IC7
27403-0010 IC SM 93C46 1K(64x16) EEPROM IC15
27413-0420 IC SM 32Kx8 CMOS RAM 70-120ns IC8
28502-0020 RESONATOR CERAMIC 12MHz XTL1
35555-3470 PCB-GPIB/RS232 INTERFACE
PCB ASSEMBLY – KEYBOARD ( 44117-0060)
Part Number Description Position
20612-0012 WASHER FIBRE 15.88MM OD FIT BETWEEN REAR OF PCB AND ENC1.
ENC1 TO HAVE TAB BENT FLAT.
22224-0020 ENCODER ROT 24 POSITION ENC1
25061-0300 LED - SM - RED 3.2 X 2.8MM LED1, LED3-8, LED11, LED15,LED20, LED24
25061-0301 LED - SM - YELLOW 3.2 X 2.8MM LK17,18,19, 21, 22, 23
25061-1000 DISPLAY SET QL .56 LED 9MM LEG
35555-3350 PCB - KEYBOARD
43171-1310 CONN ASSY 20 WAY - 135MM
21
