PCB ASSY - AUX TERM/POWER – QL355 (44117-0110) continued/…
Part Number Description Position
23202-1240 RES 240RF W60 MF 50PPM R4, R11
23202-1249 RES 249RF W60 MF 50PPM R16
23202-1430 RES 430RF W60 MF 50PPM R15
23202-1470 RES 470RF W60 MF 50PPM R13-14
23202-1487 RES 487RF W60 MF 50PPM R1
23202-1649 RES 649RF W60 MF 50PPM R2
23202-1750 RES 750RF W60 MF 50PPM R7-10
23202-2180 RES 1K80F W60 MF 50PPM R5
23202-2270 RES 2K70F W60 MF 50PPM R6
23202-2560 RES 5K60F W60 MF 50PPM R12
23202-3220 RES 22K0F W60 MF 50PPM R3
23424-0443 CAP10NZ 1KV CER D10 P5 C3, C6
23557-0530 CAP 100U 16V ELEC P2.5 C4
23557-0647 CAP 10U 35V ELEC P2 C9
23557-9122 CAP 4700U 16V ELEC P7.5 C1-2
23620-0246 CAP 100NK 63V P/E P5 C5, C8
25061-0200 LED - T1 ROUND (3mm) - RED LED1
25115-0907 DIO 1N4002 B/R D1-5
25117-0020 DIO 1N5401 D6
25336-5590 TRAN PNP BC559C Q1
27001-0020 OPTO-COUPLER CNY17-3. IC1-2
27103-0003 IC LM393 IC5
27160-0044 IC V/REG MIC2941ABT IC3
27160-0900 IC V/REG 431TO-92 IC4
35555-3730 PCB - AUX TERM/POWER
MECHANICAL ITEMS - QL355 & QL355P
Part Number Description Position
20010-0254 RIVET SNAP-LOCK 4.1D X 5.5T FAN
20030-0240 WASHER 4BA ZPST TERMINAL
20030-0263 WASHER M3 ZPST REMOTE SENSE TO TERMINAL,
POWER PCB, TERMINAL PCB,
F/PANEL BRACKET TO POWER PCB,
BARRIER BLOCK, BRACKET GPIB PCB
20030-0264 WASHER M2.5 ZPST F/PANEL SUPPORT BRACKET
20037-0301 WASHER M3 SHK/PROOF I/T ZPST F/PANEL TO CHASSIS, FAN TO CHASSIS,
BRACKET TO CHASSIS.
20037-0304 WASHER M4 SHK/PROOF I/T ZPST FRONT FEET
20037-0401 SOLDER TAG SHAKEPROOF - M4 EARTH
23
