MECHANICAL ITEMS - QL564/564P continued/…
Part Number Description Position
20234-0012 SCREW M3 X 8 PNHDPZ ZPST F/PANEL TO CHASSIS,
FAN TO CHASSIS,
REAR BRACKET TO CHASSIS
F/PANEL BRACKET TO POWER PCB,
BRACKET GPIB PCB
20234-0016 SCREW M4 X 16 PNHDPZ ZPST FEET
20234-0024 SCREW M3 X 16 PNHDPZ ZPST TERMINAL PCB, REMOTE SENSE
20234-0025 SCREW M3 X 12 PNHDPZ ZPST BARRIER BLOCK
20234-0027 SCREW M3 X 6 PNHDPZ ZPST POWER PCB
20234-0028 SCREW M4 X 10 PNHDPZ ZPST FRONT FEET
20236-0010 SCREW M4 X 12 TAMPERPROOF EARTH
20611-0050 WASHER NYLON M2.5 KEYBOARD TO FRONT PANEL
20620-0010 CLIP - ENCODER KNOB
20651-0016 CLIP CABLE RICHCO MWSEA2-2-01 MTG TO FAN BRKT
20653-0204 CABLE TIE 100 X 2.5MM MAINS TO CHASSIS, TERMINAL PCB
20661-0222 SPACER Hex M3 x 10 NPBR FRONT PANEL SUPPORT BRACKET
20661-0278 SPACER HEX 4BA X 9.53 NPBR FRONT PANEL
20661-0282 SPACER Rnd 3.7 ID x 3.2 L Nyl TERMINALS
20661-0290 SPACER Clr No.4 X 22.2mm Nyl POWER TOP
20661-9111 SPACER Hex M3 x 6 NPBR REMOTE SENSE PCB
20662-0570 FOOT SELF ADHESIVE GREY FRONT FEET
20662-9101 INSTRUMENT FOOT BACK FEET
22040-0030 FERRITE SLEEVE APPROX 8/16/14L FOR OUTPUT LEADS FOR
6 SENSE WIRES
FOR REAR TERMINAL LEADS
22115-0670 TRANSFORMER - QL564
22219-0090 SWITCH ROCKER DPST GREY
22315-9502 FUSE 2A ANTI SURGE HBC 230V
22315-9503 FUSE 4A ANTI SURGE HBC 115V
22467-0010 TERMINAL BARRIER BLOCK 4W 5A REAR PANEL TERMINALS
22491-0120 MAINS LD 2M ST IEC/UK PLUG 5A
22491-0270 MAINS LD 2M ST IEC/EUR PLUG
22491-0040 MAINS LD 2M ST IEC/USA PLUG
22520-0200 AC RECEP 10AMP FUSED SNAP-IN
22571-0675 TERMINAL TP/2 RED/GREY 12
22571-0685 TERMINAL TP/2 BLACK/GREY 12
22571-0691 WASHER ALUMINIUM FOR TP2E TERM
22571-0696 TERMINAL TP/2 GREY/GREY
