Apollo Modular Gym System (Base Unit) Fold-Out Page 20PARTS LIST
REV1
ITEM NO. DESCRIPTION PART NO. QTY. QTY. ITEM NO. DESCRIPTION PART NO. QTY. QTY. ITEM NO. DESCRIPTION PART NO. QTY. QTY.
1 ACTUATOR ARM UP0344 1
59 ABS PIPE 2 X 19 3/8 BNH1639 2 115 NYLON BUSHING 1 X 1 1/2 X 7/8 X 1 3/4 X 1/8 BNH0531 4
2 BACK PAD ADJUSTABLE BRACKET UP0554 1
60 ALUMINUM CAM PLATE 3/4 X 5" RADIUS BNH1153 2 116 NYLON FLAT WASHER 1 X 1 1/4 X 1/16 BNH0393 2
3 BACK PAD ADJUSTABLE TUBE UP0347 1
61 ALUMINUM CAP 1.020" RD (CAP-100) BNH0537 4 117 NYLON FLAT WASHER 3/8 ID X 3/4 OD X 1/16 THK BNH0248 4
4 BENCH PRESS ADJUSTABLE SEAT FRAME UP0676 1
62 ALUMINUM CAP 1.270" RD (CAP -125) BNH0538 4 118 NYLON INSERT JAM LOCK NUT B/O 3/8-16 BNH0365 18
5 BENCH PRESS BACK PAD UP0370 1
63 ALUMINUM COLLAR 1.0312 ID X 1.521 OD X .500 THK. BNH1519 2 119 NYLON INSERT LOCK NUT B/O 3/8-16 BNH0214 46
6 BENCH PRESS SEAT PAD UP0372 1
64 ALUMINUM FOOT ROLL HOLDER 1 5/16 ID X 4 1/2 OD X 3/4 BNH1509 4 120 NYLON INSERT LOCK NUT B/O 5/16-18 BNH0215 2
7 BOTTOM CONNECTOR PRESS BAR/PEC FLY UP2006 1
65 ALUMINUM FOOT ROLL HOLDER 2 3/8 ID X 4 1/2 OD X 3/4 BNH1510 4 121 NYLON SPACER 3/8 X 3/4 X 3/8 BNH0392 2
8 CABLE RETAINER BRACKET UP0014 4
66 ALUMINUM PULLEY 3/8" X 3 1/2" BNH1266 2 122 PLASTIC END CAP 2 X 3 BNH0606 4
9 CHROME PEC DEC SWIVEL HANDLE UP0324 2
67 ALUMINUM PULLEY 3/8" X 4 1/2" BNH0069 19 123 PLASTIC INSERT CAP 1 3/4" SQ BNH0053 2
10 CHROME SOLID GUIDE ROD 3/4 X 72 UP0124 8
68 ALUMINUM WASHER 3/8 X 2.584 OD X .15 THK. BNH1521 2 124 PLASTIC INSERT CAP 1" X 2" BNH0005 4
11 CIRCULAR PLATE W/AXLE UP0671 1
69 BALL BEARING #W 516 BNH0628 2 125 PLASTIC INSERT CAP 2 X 3 BNH0052 1
12 CLOSED-END DOUBLE PULLEY BRACKET UP0329 1
70 BRONZE BUSHING 1 X 1 1/4 X 3/4 X 1 1/2 X 1/8 BNH0527 12 126 PLASTIC INSERT CAP 2" SQ BNH0012 9
13 FOAM ROLL 1 X 5 1/2 X 7 1/4 UP0350 2
71 BUTTON HEAD SOCKET CAP SCREW B/O 3/8-16 X 1 BNH0115 8 127 PLASTIC TIES 14 1/2" BNH0703 2
14 FOAM ROLL 2 X 5 1/2 X 18 UP2031 2
72 BUTTON HEAD SOCKET CAP SCREW B/O 3/8-16 X 1 1/4 BNH0896 2 128 PLASTIC TUBE GUIDE W/LIP-TEETH 2 1/4" SQ BNH0059 2
15 FOOT ROLL TUBE 1 X 29 UP0974 1
73 CHROME CAP 2" RD BNH1137 2 129 PULL PIN 1/2 X 2 7/8 (YELLOW KNOB) BNH0641 1
16 FRONT UPRIGHT UP2008 1
74 CHROME WASHER 3/8 X 1 1/2 BNH1015 6 130 PULL PIN 1/2 X 3 1/2 (YELLOW KNOB) BNH0603 4
17 GUIDE ROD RETAINER UP2033 3
75 CLEVIS BRACKET 3/16" BNH0076 1 131 PULL PIN 1/4 X 3 1/2 (YELLOW KNOB) BNH0713 1
18 GUIDE ROD RETAINER PRESS BAR STATION UP2010 1
76 COIL CHAIN Z/P 3/16 X 8 BNH1214 1 132 PVC 1 X 8 3/4 BNH1611 2
19 HANDLE LEFT SIDE UP0271 1
77 DECAL-1" RD SILVER MYLAR CIRCLE BNH0015 4 133 RETAINING SNAP RING EXT .925 X 1 X .042 BNH0419 2
20 HANDLE RIGHT SIDE UP0270 1
78 DECAL-ADJUST CABLE HERE BNH0789 2 134 ROLL PIN Z/P 3/8 X 1 1/2 BNH0483 1
21 LAT BAR HOLDER 2 X 3 UP0327 1
79 DECAL-CAUTION 1 3/4 X 5 1/2 BNH0126 1 135 RUBBER BUMPER 3/8 X 1 1/2 BNH0514 1
22 LAT CABLE UP2021 1
80 DECAL-CAUTION LAT BAR HOLDER 5 X 1 BNH0140 1 136 RUBBER DONUT 3/4 X 2 1/2 BNH0068 8
23 LEG EXTENSION ARM SUPPORT UP2028 1
81 DECAL-DANGER TIGHTEN THIS RET..., 3/4 X 1 1/2 BNH0142 6 137 RUBBER GRIP 1 ID X .125 X 8 BNH0966 2
24 LEG EXTENSION BACK PAD UP0371 1
82 DECAL-EXERCISE LAT, VERTICAL PRESS, PEC FLY & LEG EXT BNH1673 1 138 RUBBER GRIP 1 ID X .125 X 8 1/2 BNH1075 2
25 LEG EXTENSION BOTTOM CONNECTOR UP2001 1
83 DECAL-EXR LAT, MID ROW, PEC FLY, LEG EXT & MULTI-PRESS BNH1674 * 1 139 RUBBER GRIP 1 X 6 1/4 BNH0296 4
26 LEG EXTENSION CABLE UP2025 1
84 DECAL-FOR BEST PERFORMANCE 1 1/4 X 1 1/2 BNH0143 4 140 RUBBER GRIP 1.1875 ID X .125 X 13 BNH0853 * 2
27 LEG EXTENSION FRONT FRAME UP0666 1
85 DECAL-WEIGHT NUMBERS REF TP-10 (200 lbs) BNH1542 4 141 RUBBER GRIP 1.1875 ID X .125 X 4 5/8 BNH1643 6
28 LEG EXTENSION SEAT FRAME UP2002 1
86 DECAL-WARNING KEEP HANDS AND FINGERS... BNH0620 1 142 RUBBER GROMMET 3/4" ID BNH0401 8
29 LEG EXTENSION SEAT PAD UP0348 1
87 EDGE PROTECTOR CHROME 18 GA X 72 BNH1836 8 143 RUBBER STOPPER 1 ID X .187 X 3 BNH0976 2
30 LONG ADJUSTABLE STOPPER UP0331 1
88 FINISHED HEX NUT B/O 1/2-13 BNH0201 4 144 SHOULDER BOLT ALLOY 3/8 X 3/4 BNH0718 2
31 MAGNETIC SELECTOR PIN W/COIL 3/8 X 4 UP3035 4
89 FLAT PHILLIPS MACHINE SCREW 8-32 X 1/4 BNH0408 2 145 SNAP LINK Z/P 8MM X 80MM BNH0065 3
32 MID ROW HANDLE LT SIDE UP4236 * 1
90 FLAT PHILLIPS SCREW ZINC # 2 X 1/2 BNH1480 2 146 SOCKET HEAD CAP SCREW B/O 1/4-20 X 3/4 BNH0452 2
33 MID ROW HANDLE RT SIDE UP4237 * 1
91 FLAT PHILLIPS SCREW ZINC # 5 X 1/2 BNH1481 4 147 SOCKET SET SCREW ALLOY 1/4-20 X 1/4 BNH0790 1
34 MID ROW PULL ARM UP4221 * 1
92 FLAT WASHER B/O 3/4 X 2" BNH0878 8 148 SOCKET SET SCREW ALLOY 10-32 X 1/4 BNH0473 4
35 PEC DEC ARM LEFT SIDE UP0819 1
93 FLAT WASHER SAE B/O 3/8" BNH0239 101 149 SOCKET SET SCREW ALLOY 10-32 X 1/8 BNH0473 24
36 PEC DEC ARM RIGHT SIDE UP0818 1
94 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 BNH0275 2 150 SOCKET SET SCREW ALLOY 3/8-16 X 1/2 BNH0474 6
37 PEC DEC CABLE UP2022 1
95 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 1/2 BNH0303 1 151 SPLIT HEX TAP BOLT GR-5 B/O 1/2-13 X 3 1/2 BNH1131 2
38 PIVOT ARM LEG EXTENSION UP2030 1
96 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 1/4 BNH0273 10 152 SPLIT LOCK WASHER B/O 3/8" BNH0658 10
39 PIVOT AXLE 1 X 8 1/8 UP0152 2
97 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 3/4 BNH0274 8 153 SPLIT LOCK WASHER Z/P 1/2" BNH0572 4
40 PIVOT AXLE 1 X 9 UP4238 * 1
98 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 BNH0279 3 154 TUFFSTUFF LOGO ALUMINUM LARGE BNH1324 2
41 PRESS BAR SELECTOR HOUSING UP0326 1
99 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 1/2 BNH0276 3 155 TUFFSTUFF LOGO ALUMINUM SMALL BNH1323 2
42 PRESS BAR (DETACHABLE HANDLES) UP3573 1
100 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 3/4 BNH0278 2 156 TURN/PULL PIN W/KNOB AND LOCK BNH0989 2
43 REINFORCEMENT PLATE 1/4 X 2 X 8 1/2 UP2106 3
101 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3 1/4 BNH0312 17 157 URETHANE BUMPER 1 3/4 BNH0229 8
44 REMOVABLE HANDLE LT SIDE UP3574 1
102 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3/4 BNH0283 16 158 URETHANE BUMPER 962 BNH0244 2
45 REMOVABLE HANDLE RT SIDE UP3575 1
103 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 4 BNH0285 2
46 SAFETY SHIELD COVER PLATE 1 1/2 X 5 UP1767 1
104 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 4 1/4 BNH0317 11
* Mid Row Station Item Quantities
47 SWIVEL FOAM ROLL TUBE UP2026 1
105 HEX KEY 3/32" BNH0372 1
48 TOP ADJUSTABLE LEG HOLDER TUBE UP0672 1
106 HEX KEY ALLOY 1/8" BNH0767 1
49 TOP PULLEY ASSEMBLY UP2007 1
107 HEX KEY ALLOY 3/16" BNH0371 1
50 WEIGHT SHIELD UP2017 3
108 HEX KEY ALLOY 7/32" BNH0575 2
51 WEIGHT SHIELD (APT-5.1) UP1750 1
109 LABEL-ADJUSTMENT BACK PAD 9/16 X 7.5 BNH0080 1
52 WEIGHT SHIELD HOLDER UP2016 8
110 LABEL-ADJUSTMENT PRESS BAR 9/16 X 6 BNH0079 1
53 WEIGHT STACK FRAME UP2000 1
111 LAT BAR 48" BNH0295 1
ITEM NO. DESCRIPTION PART NO. QTY. QTY.
54 WEIGHT STACK SPACER 4" UP0786 2
112 LOW ROW BAR 20" BNH0294 1
66 NYLON PULLEY 3/8 X 3 1/2 BNH0553 2
56 10 LB STEEL WEIGHT PLATE BLACK 4 9/16 X 9 7/16 BNH1650 76 113 METAL HINGE BNH0046 2
67 NYLON PULLEY 3/8 X 4 1/2 BNH0506 19
58 10 LB TOP PLATE W/ADJ SLTR BAR 19 BLK WTS BNH1982 4 114 NYLON BALL 1 3/4 X 5/16 BNH0047 1
All parts same as Deluxe, except for the parts listed below
Parts List (Base Unit)
Apollo Modular Gym Systems (Standard)
Apollo Modular Gym Systems (Deluxe)
Parts List (Base Unit)
CHART
BOLD FONT = SUB-ASSEMBLY PARTS
REGULAR FONT = HARDWARE
