TuffStuff TS-1000 - Page 13

IG. 42 Next, route the Lat Cable (#33) through the Closed-End Adj.
D
ouble Pulley Bracket (#30) and under the Nylon Pulley 4 1/2 Rd. (#67-
a
beled A7), as shown above.
Note: Refer to the Cable Mapping Diagram on page 24 for further
detailed illustration of the Lat Cable (#33) routing.
FIG. 43 Next, route the Lat Cable (#33) through the Adjustable Pull
e
Bracket (#27) and over the Nylon Pulley 4 1/2 Rd. (#67-Labeled A8),
a
shown above.
Note: Refer to the Cable Mapping Diagram on page 24 for furth
e
detailed illustration of the Lat Cable (#33) routing.
IG. 40 Next, route the Lat Cable (#33) up and over the Nylon Pulley
-
1/2 Rd. (#67-Labeled A4).
Note: Refer to the Cable Mapping Diagram on page 24 for further
detailed illustration of the Lat Cable (#33) routing.
FIG. 41 Next, continue to route the Lat Cable (#33) over the Nylo
Pulley 4 1/2 Rd. (#67-Labeled A5), then through the Front Upright (#
6
and over the Nylon Pulley 4 1/2 Rd. (#67-Labeled A6).
Note: Refer to the Cable Mapping Diagram on page 24 for furth
e
detailed illustration of the Lat Cable (#33) routing.
T
S-1000 Home Gym w/Adjustable High-Low Pulley System 12
