24
COULTER PRESSURE INCREASES THE RISK OF BLOCKING AND PUTS
UNNECESSARY STRAIN ON THE BODY STRUCTURE OF THE MACHINE.
Storage
When the machine is not used, it must be stored cleaned and serviced in a covered shelter. Lower down the
machine. Do not leave the machine supported by the tractor’s hydraulics. Empty the hoppers of fertilizer and
seed.
Wash the machine inside and out with water. Use the pressure washer with caution (maximum water
temperature of 60 degrees, pressure 100 bar), and do not aim the jet directly to the bearings. Grease the
machine according to the instructions. Spots where the paint has worn off can be protected with an anti-
corrosive agent.
During the cleaning, record any faults you observe. It is a good idea to order spare parts well in advance of
the season to have the repairs made in time.
18. TECHNICAL SPECIFICATIONS
Type
NOVA 3000
NOVA 4000
Working width (m)
3.0
4.0
Hopper volume (l)
-total
-seed, minimum
-seed, maximum
-fertilizer, maximum
3250
1330
2280
1920
4500
1840
3160
2660
Basic machine weight (kg)
-empty
-Hoppers full of wheat and
fertilizer
3750
6050
5475
8590
Basic machine dimensions (cm)
-height to hopper edge
-width
--length without drawer
215
300
290
215
400
290
Mark wheels
-size
-number
-pressure (bar)
7.50 – 16
12
1.5 – 2.0
7.50 – 16
16
1.5 – 2.0
Coulter pressure
-coulter weight/coulter (N)
-weighting adjustment during
drive
400 - 2200
standard
400 - 2200
standard
Number of coulters
24
32
