Opposite Side
Ask the subject to stop holding the attachment.
While the subject still lays on the chair, slide the chair away from the dynamometer.
Remove the shoulder attachment from the dynamometer input arm and put it back turning it
around.
Adjust the chair and the dynamometer in accordance to the quick reference above.
Follow the steps 6 -9 as described above.
Seated Position
Attachments Needed
Dynamometer: Angle Adapter ADL4 and Wrist Adapter ADW1
Chair: Footrest, which is a combination of ADS1 and ADT2 (optional)
Put the mechanical stops to “B” blue and “B” red.
Collect angle/elbow attachment and the handle grip. Combine them to form the attachment shown
in the photo.
Attach the adapter to the dynamometer by sliding it in the input arm from the top, short side.
.
