7.6 Electrical Requirements
210/230VAC, 50Hz, 16 amps
Requires 16A isolated dedicated service
Hospital Grade Plug must be rated for 230VAC, 16 amps minimum
WARNING: To avoid the risk of electric shock, this equipment must only be
connected to a supply mains with protective earth
7.7 Classification
Type of protection against electrical shock: Class I
IP Protection degree: IP20
Applied Parts Type: B
Software Class: I
7.8 Operating Conditions
Ambient temperature +10°C to +40°C
Relative humidity 30% to 75%
Atmospheric pressure 700hPa to 1060hPa
7.9 Transport and Storage Conditions
Ambient temperature -10°C to +40°C
Relative humidity 10% to 95%
Atmospheric pressure 500hPa to 1060hPa
7.10 Technical Description
Technical description can be found at the service manual
7.11 EMC Informations
By larger interference pulses on the main voltage the program can be stopped and the unit reset to the
initial condition. However, in such a case the patient cannot be subjected to any uncontrolled move.
Such interference can be generated by working RF thermotherapy units ( e.g. short-wave or microwave
ones) as well well as RF surgical devices when their distance to the Isoforce is below 3m.
Pacemaker patients shall only be treated with the Isoforce after consulting a competent physician.
