TurboChef HHB-8028

65
COMPREHENSIVE PART LISTING
PART PART NUMBER ILLUSTRATION
Air Diverter Plate HHB-8030 Figure 59, page 57
Blower Motor HHB-8106 Figure 55, page 53
Blower Motor Controller 100443 Figure 39, page 32
Blower Motor Cover NGC-1081 Figure 55, page 53
Blower Motor Mounting Plate HHB-8009 Not labeled
Bracket – Blower Motor Controller HHB-8111 Figure 39, page 32
Bracket – Display (x2) HHB-8130 Figure 41, page 34
Bracket – Rack Oscillator Motor HHB-8049 Figure 46, page 41
Bushing – Swing Arm Assembly (x2) 100152 Figure 58, page 56
Cable – Smart Card Reader 103023 Figure 45, page 38
Cable Mount – Adhesive (x3) 100174 Not labeled
Catalytic Converter HHB-8108 Figure 59, page 57
Component Plate HHB-8055 Not labeled
Component Plate Shield
HHB-8088 Not labeled
Cooling Fan F
inger Guard 100087 Figure 40, page 33
Cooling Fans – Inlet/Exhaust 100516 Figure 40, page 33
Cover – Cooling Fan (Exhaust) HHB-8079 Figure 40, page 33
Cover – Drag Link/Left S
wing Arm Assembly HHB-8053 Not labeled
Co
v
er – Right Swing Arm Assembly HHB-8052 Not labeled
C
rank – Rack Oscillator Motor HHB-8045 Figure 46, page 41
D
isplay
100505
F
igure 41, page 34
D
isplay K
eypad
HHB-8064
Figure 42, page 35
D
oor
HHB-8080-2
F
igure 51, page 49
D
oor A
ctuator
102789
Figure 54, page 52
D
oor G
asket
HHB-8101
Figure 52, page 50
D
oor H
inge
102807
Figure 53, page 51
D
oor I
nner P
late HHB-8083 Figure 52, page 50
D
oor R
eceiv
er HHB-8084 Not labeled
D
oor S
witch
102788 Figure 43, page 36
Door S
witch/A
ctuator Mounting Bracket HHB-8086 Figure 43, page 36
Drag Link – S
wing Arm Assembly
HHB-8044 Figure 58, page 56
Drain Lid
HHB-8141 Figure 59, page 57
Drain P
an 101091 Figure 59, page 57
Drain P
an Rack HHB-8105 Not labeled
C
OMPREHENSIVE PART LISTING
