TurboChef HHB-8028

67
COMPREHENSIVE PART LISTING
P
ART PART NUMBER ILLUSTRATION
Power Cord Mounting Bracket NGC-1167 Not labeled
Power Supply 101206 Figure 45, page 38
Push Nut (x2) 101293 Figure 53, page 51
Rack HHB-8104 Figure 57, page 55
Rack – Offset (Accessory) HHB-8118 Not labeled
Rack Oscillator Motor HHB-8135 Figure 46, page 41
Relay 101273 Figure 45, page 38
Retaining Ring – Rack Oscillator Motor 101297 Figure 46, page 41
Retaining Ring – Swing Arm Assembly 101297 Not labeled
Ribbon Connector – Display 103024 Not labeled
Screw – Air Diverter Plate (x4) 101688 Figure 59, page 57
Screw – Blower Motor Controller (x4) 101688 Figure 39, page 32
Screw – Blower Motor Controller Bracket (x4) 101688 Figure 39, page 32
Screw – Blower Motor Cover (x8) 101688 Figure 55, page 53
Screw – Component Plate Standoff (x4) 102921 Not labeled
Screw – Cooling Fan Assy (4 x 2 fans = 8) 101694 Figure 40, page 33
Screw – Cooling Fan Cover (x3) 101688 Figure 40, page 33
Screw – Display (x4)
101520 Figure 41, page 34
Screw – Door Actuator (x2) 101421 Not labeled
Screw – Door Hinge (1 per hinge = 2 total) 101402 Figure 53, page 51
Screw – Door Hinge Receiver (x4) 101693 Not labeled
Screw – Door Inner Plate (x10) 102809 Figure 52, page 50
Screw – Door Switch/Actuator (x2) 101421 Figure 43, page 36
Screw – Drain Pan Rack (x3) 101688 Not labeled
Screw – Electrical Plate (x2) 102911 Figure 50, page 45
Screw – Front Side Panel (x2 per side) 101663 Figure 41, page 34
Screw – Fuse Cover 101688 Figure 44, page 37
Screw – Heater Element (x6) 101688 Figure 56, page 54
Screw – I/O Control Board (x4) 102910 Figure 45, page 38
Screw – I/O Control Board Standoff (x4) 102911 Not labeled
Screw – Power Supply (x3) 102911 Figure 45, page 38
Screw – Rack Oscillator Motor (x2) 101672 Figure 46, page 41
Screw – Rack Oscillator Motor Bracket (x2) 101688 Figure 46, page 41
Screw – Rack Oscillator Motor Crank 101714 Not labeled
Screw – R
elay (x2)
101687
F
igur
e 45, page 38
