INFO MODE
Info Mode
To access Info Mode, touch the “i” icon when both
ovens are off or cooling down. From the Info Mode
screen (Figure 6), access:
- Information screen
- Counters screen
- Options screen
- Settings screen
- Service mode
- MFG mode
To access each screen, touch the corresponding icon
(e.g. touch “COUNTERS” to access the Counters
screen).
The Options, Settings, Service, and MFG screens
require a passcode to access. Touch “Login” and,
when prompted, input the password 9 4 2 8 and
touch the check icon in the bottom-right corner of
the screen (Figure 7).
Information Screen
From the Information screen (Figure 8), view:
- Serial Number
- Menu Version
- Sage Firmware Version
- Phoenix Firmware Version
- Service Number
- Language
- VAC (Voltage) - View Incoming
Counters Screen
From the Counters screen (Figure 9), view:
- Cook Counter
- Total Cook Time in cumulative hours
- Total Time (oven on) in cumulative hours
- Power Cycles: The number of times the oven
has cycled power.
- Erase Counters (option available while logged in)
- Fault Log
Counters Screen - Fault Log
The fault log is split into the “Count” screen and the
“History” screen.
Count Screen: Displays the number of times a fault
has occurred (Figure 10).
History Screen: Displays the timestamp of each fault
occurrence (Figure 11).
Touch the “COUNT” / “HISTORY” toggle on the
left-side of the screen to switch between these screens.
Figure 6: Info Mode
Info Mode
Serial Number:
HHDXXXXXXX
Menu Version:
HHD-XXXX-XX
Sage Firmware:
160601
Phoenix Firmware:
160603
Service Number:
1.800.90TURBO
Language:
English
VAC:
240V
INFORMATION
C
OU
NTERS
Login
Figure 8: Information Screen
Info Mode
Serial Number:
HHDXXXXXXX
Menu Version:
HHD-XXXX-XX
Sage Firmware:
160601
Phoenix Firmware:
160603
Service Number:
1.800.90TURBO
Language:
English
VAC:
240V
INFORMATION
COUNTERS
O
PTI
O
N
S
S
ETTING
S
S
ERVI
CE
M
F
G
Figure 10: Fault Log - Count
Info Mode
F1-1: 001
F1-2: 000
F2-1: 000
F2-2: 000
F6: 000
F7-1: 001
F7-2: 001
F8-1: 000
F8-2: 000
F9-1: 001
F9-2: 000
F10: 001
F12: 000
FAULT LOG
COUNT HISTORY
BACK TO
COUNTERS
Figure 7: Passcode Screen
Passcode:
123
456
7 8 9
0
Figure 11: Fault Log - History
Figure 9: Counters Screen
Info Mode
Cook Counter:
0007
Total Cook Time:
000035
Total Time:
000237
Power Cycles:
000001
Login
Fault Log
Erase Counters
I
NF
O
RMATI
ON
COUNTERS
O
PTIONS
S
ETTING
S
S
ERVI
C
E
MF
G
Info Mode
F1-1: 2016-01-01 23:43
F9-1: 2016-01-01 16:01
F10: 2016-01-01 14:37
F7-2: 2016-01-01 12:12
F7-1: 2016-01-01 08:22
F10: 2016-01-01 02:59
FAULT LOG
COUNT HISTORY
BACK TO
COUNTERS
