turbofan E23D3 Service Manual

Operation
9
Turbofan E20D Series Convection Ovens © Copyright Moffat Ltd. 10 February 2016.
Amendment 1
Manual Mode
In Manual Mode the oven settings are.
- Temperature - 60-260C / 140-500F.
- Timer - 0-180min or Infinite.
- Steam - St0 - St5.
Program Mode
In Program Mode 20 Programs can be programmed.
Up to 3 cooking stages can be set in each of the programs.
In each stage the following settings are possible.
- Temperature - 60-260C / 140-500F.
- Time - 0-180min or Infinite.
- Steam - St0 - St5.
- End of stage alarm - On / Off.
Steam Mode
The steam function can be used in two different ways.
The ‘Operator Setting’ StE determines the function.
(Refer to the ‘Controller Operator Settings’ section for details on
how to change the settings).
 With StE = 0, the steam key operates as a momentary key,
steam is injected into the oven for as long as the key is
pressed. This is the Default Setting.
 With StE = 1 to 5, the steam key will start a sequence of
steam pulses, with 1 to 5 being the number of pulses.
Additionally, with StE = 1 to 5, the steam level setting can be
quickly changed by holding the steam key for three seconds
and choosing level St1 to St5.
In Program Mode:
Each stage of a program can be set to steam level St0 to St5.
Steam level St0 means that there is no automatic steaming in the
program / stage. Steam can be manually injected at any time
during program cooking.
Steam levels St1 to St5 means the program / stage starts with a
sequence of steam pulses. Steam can be manually injected at any
time after the automatic steaming is finished.
If StE = 0: Hold steam key for steam.
If StE = 1 to 5: Press steam key to start a steam sequence.
Quick access to levels St1 to St5 is also available when in Program
Mode when StE = 1 to 5.
For more information on setting steam levels in programs, refer to
the ‘Programming’ section of this manual.
In Manual Mode / Cooking with Timer:
Steam can be injected at any time.
If StE = 0: Hold steam key for steam.
If StE = 1 to 5: Press steam key to start a steam sequence.
NOTE: When using the steam functions, if the Oven
Temperature is BELOW 100°C (212°F), water may
pool in oven as temperature will be too low to create
steam.
(Steam Mode is available by default - to disable the Steam Mode,
enter the ‘Operator Settings’ and change the enable steam function
ESt to ‘no’.
Refer to section ‘Controller Operator Settings’ for further details).
