turbofan E23D3 User Manual

Replacement Parts List
23
Item Description
E23D3 E27D2 / E27D3 E28D4
238194 Digital Controller Kit
  
237447K Temperature Probe PT1000 Kit
  
234429 Transformer, 208 / 240V x 12VAC, SEC 20VA
  
234447 Knob T/Fan
  
238407 Encoder
  
234088
Oven Element, 2800W, 230 - 240V US, CAN, AU, NZ, UK, XP.

 D2 only

234089
Oven Element, 2800W, 208 - 220V US, CAN, XP.

 D2 only

234107
Oven Element, 4500W, 208 - 220V US, CAN, XP.
 D3 only
234108
Oven Element 4500W, 230 - 240V US, CAN, AU, NZ, UK, XP.
 D3 only
236264
Element Gasket
  
235585 Fan Motor Kit
  
238989 Motor Shaft Seal (part of Fan Motor Kit above)
  
234251 Capacitor 5uF 208 - 240V
  
238881 Relay, 30A, DPST HF92F, 240V
 
234821 Overtemp, 355°C - 20K
  
233862 Door Microswitch
  
238981 Water Solenoid
  
021057 Spray Nozzle
  
025922 Adaptor 3/4” BSP/GHT, Brass (USA / CA / MX only).
  
021527 Washer Rubber 23 x 14.5 x 1.5mm (USA / CA / MX only).
  
021352 Oven Lamp Lens
  
231814 Lamp Bulb G9 25W, 230V Halogen
  
021354 Oven Lamp Gasket
  
234802 Fuse Holder
 D3 only

234803 Fuse 10A
 D3 only

233913 Door Inner Glass - E23

233368 Door Inner Glass - E27

233346 Door Inner Glass - E28

233293 Door Hinge - E23

233294 Door Hinge - E27

233295 Door Hinge - E28

232667 Door Seal - E23

232666 Door Seal - E27

234466 Door Seal - E28

232379 Leg Adjustable (73 - 80 mm)
  
232682 Side Rack LH, E23

232683 Side Rack RH, E23

234721 Side Rack LH, E27, 2 Tray.

234722 Side Rack RH, E27, 2 Tray.

233558 Side Rack LH, E27, 3 Tray.

233559 Side Rack RH, E27, 3 Tray.

238214 Side Rack LH, E27, 2, Tray 600 x 400.

238215 Side Rack RH, E27, 2, Tray 600 x 400.

238216 Side Rack LH, E27, 3, Tray 600 x 400.

238217 Side Rack RH, E27, 3, Tray 600 x 400.

233556 Side Rack, E28

238218 Side Rack LH, E28, 600 x 400.

238219 Side Rack RH, E28, 600 x 400.

233564 Oven Rack E23

233565 Oven Rack E27, E28
 
238220 Oven Rack E27, E28, 600 x 400.
 
233552 Thumb Screw
  
When ordering replacement parts, please quote the part number and the description as listed below. If the part required is not listed
below, request the part by description and quote model number and serial number which is shown on the Technical Data Plate.
Important:
Only genuine authorized replacement parts should be used for the servicing and repair of this oven. The instructions
supplied with the parts should be followed when replacing components.
For further information and servicing instructions, contact your nearest authorized service provider or Turbofan Dealer.
