· 11
This diagram shows the correct way to connect your battery to the MEGA 400W×2 while
charging in the balance charge program mode only.
Failure to connect as shown in this diagram will damage this charger.
To avoid short circuit between the charge lead always connect the charge cable to the
charger first, then connect the battery. Reverse the sequence when disconnecting.
WARNING:
Balance socket:
The balance wire attached to the battery must be connected to the charger balancing
port. Take care to maintain correct polarity!
(Wiring diagram: see below.)
LITHIUM POLYMER BALANCE CHARGE PROGRAM
CONNECTION DIAGRAM
