6.7 Spare parts
Please quote the equipment serial number with every order for components!
Panel-shape models
Models PMD2PLUS/PZ
Rev.1.000
HIPEPLUS/PZ
Rev.2000
SMD600PLUS/PZ
Rev.1.002
02PN20/PZ
Rev.1.001
PMD3PLUS/PZ
Rev.1.000
Description Code Code Code Code Code
Plastic case control unit with connecting cables 64824 64083 61013 64962 67561
Metal case control unit with connecting cables 64286 64084 61016 64963 67562
Front cover with lock of Plastic case control unit 24873 24873 24873 24873 24873
Installation kit for Plastic case control unit 49961 49961 49961 49961 49961
Installation kit for Metal case control unit 49962 49962 49962 49962 49962
Keys of the keypad (4) 29415 29415 29415 29415 29415
RX antenna (adapted for photocells installation) * 54379 66334 63494 51787 51769
TX antenna (adapted for photocells installation) * 54380 66333 63493 54428 51771
Electronic cards of the antenna dual colour archway LED bar 45401 63496 63496 45401 45401
720mm cross-bar with holes 55639 55639 55639 55639 55639
720mm cross-bar without holes 55640 55640 55640 55640 55640
760mm cross-bar with holes 55652 55652 55652 - -
760mm cross-bar without holes 55653 55653 55653 - -
820mm cross-bar with holes 55641 55641 55641 - -
820mm cross-bar without holes 55642 55642 55642 - -
Upper cable protection cap of the panel with knobs 45663 45663 45663 45663 45663
Upper cable protection cap of the panel with screws 55154 55154 55154 55154 55154
Round photocells module 32716 32716 - - -
Standard 2 beam oval photocells module - - 46113 - -
High precision 4 beam oval photocells module - - 46112 46112 46112
Protection caps for Lower connection module 55155 55155 55155 55155 55155
Protection caps for 720mm crossbars and control unit 55644 55644 55644 55644 55644
Protection caps for 760mm crossbars and control unit 55654 55654 55654 - -
Protection caps for 820mm crossbars and control unit 55645 55645 55645 - -
Lower connection module 55637 55637 55637 - -
Emergency battery option: Lower connection module with Pb 0.8Ah battery APSM2plus/P APSM2plus/P APSM2plus/P APSM2plus/P APSM2plus/P
Pb 12V-0,8Ah battery 19 19 19 19 19
Emergency battery and Ethernet option – Lower connection module with Pb 0.8Ah batteries APSIM2plus/P
APSIM3plus/P
APSIM2plus/P
APSIM3plus/P
APSIM2plus/P APSIM3plus/P APSIM3plus/P
Long Life Crossbar Battery Back-Up option 55681 55681 55681 55681 55681
Battery compartment with batteries 49510 49510 49510 49510 49510
Pb 12V - 9Ah battery 36891 36891 36891 36891 36891
100-240V~ , 100W IP67 Power supply adaptor 48092 48092 48092 48092 48092
100-240V~ , 80W Power supply adaptor 44041 44041 44041 44041 44041
Cable for Power supply adaptor, CEE plug 1559 1559 1559 1559 1559
Cable for Power supply adaptor, UL plug 1574 1574 1574 1574 1574
Cable for Power supply adaptor, UL L5-15P twist lock plug 49040 49040 49040 49040 49040
Cable for Power supply adaptor, UK plug 1570 1570 1570 1570 1570
Column-shape models
Models PMD2PLUS/EZ Rev.1.004 02PN20/EZ Rev.1.001 PMD3PLUS/EZ Rev.1.000
Description Code Code Code
Plastic case control unit with connecting cables 64888 64966 67552
Metal case control unit with connecting cables 64889 64967 67553
Front cover with lock of Plastic case control unit 24873 24873 24873
Installation kit for Plastic case control unit 45315 45317 45317
Installation kit for Metal case control unit 45316 45318 45318
Keys of the keypad (4) 29415 29415 29415
RX antenna (adapted for photocells installation) * 54358 52859 52165
TX antenna (adapted for round photocells installation) * 54359 52961 52166
Electronic cards of the antenna dual colour archway LED bar 45401 45401 45401
720mm cross-bar with holes 45156 45156 45156
820mm cross-bar with holes 45226 - -
Cross-bar locking unit (1 piece) 24878 24878 24878
Upper cable protection cap of the panel with knobs 45417 45417 45417
Upper cable protection cap of the panel with screws 55668 55668 55668
Round photocells module 46982 - -
High precision 4 beam oval photocells module - 56109 56109
Installation kit for Plastic case control unit and photocells 45317 45317 45317
Installation kit for Metal case control unit and photocells 45318 45318 45318
Protection caps for 720mm crossbars and control unit 54113 54113 54113
Protection caps for 820mm crossbars and control unit 55667 - -
Ethernet option APSIM2plus/E APSIM3plus/E APSIM3plus/E
100-240V~ , 100W IP67 Power supply adaptor 48092 48092 48092
100-240V~ , 80W Power supply adaptor 44041 44041 44041
Cable for Power supply adaptor, CEE plug 1559 1559 1559
Cable for Power supply adaptor, UL plug 1574 1574 1574
Cable for Power supply adaptor, UL L5-15P twist lock plug 49040 49040 49040
Cable for Power supply adaptor, UK plug 1570 1570 1570
* specify the options to include with the order. Example: TX antenna with photocells:
 code of the TX Antenna
 code of the Lower connection module (panel shape only)
 code of the Kit of photocells
 code of the Electronic cards of the antenna archway LED bar (2 pieces).
