Turnstiles SMD600 PLUS - 2 Description; Composition

5
2 DESCRIPTION
2.2 Composition
CU
5
1
2
3
4
5
1
2
3
4
plastic case metal case
PSA
IP30 IP67
CU
TX
RX
Rf
C1
C2
PSA
Ph
AA
LBL
LCM
9
8
UCM-RX
UCM-TX
7
6
10
11
UPC
UPC
BAT UCM-TX
UCM-RX
LCM

11
Ph - Rf
P1
P2
R1
R2
LBL
Ph
TX
RX
Rf
C1
LCM
PSA
UPC
UPC
CU
LBL
AA
9
UCM-RX
UCM-TX
8
7
6
10
UCM-TX UCM-RX
LCM

LINE
Ph - Rf
LBL
CU - Control Unit
The control unit, available in plastic casing or metal casing, is designed to be attached directly to
the crossbar of the archway. An embedded Infra-Red interface allows the use of an accessory
remote control unit which acts as the control unit keypad. It includes also a BLUETOOTH
TM
interface for wireless connection to a PC for service operations
. Parts of the control unit:
 8-digit alphanumeric display, divided into two sections, the left part is green and the right one is red.
 sounder
 keypad for status reading and programming
 slot of the chip card reader
 security lock of the front panel
