Tuthill 3200 - Assembly Clearances

25
07
Operator’s Manual 2010 Rev B p/n 2010
MODEL GEAR END DRIVE END TOTAL CLEARANCE INTERLOBE TIP TO DOWEL TIP TO PORT
3203
0.003 – 0.006 in.
0.08 – 0.15 mm
0.005 – 0.007 in.
0.13 – 0.18 mm
0.008 – 0.013 in.
0.20 – 0.33 mm
0.004 – 0.008 in.
0.10 – 0.20 mm
0.002 – 0.005 in.
0.05 – 0.13 mm
0.005 – 0.007 in.
0.13 – 0.18 mm
3208
0.003 – 0.006 in.
0.08 – 0.15 mm
0.011 – 0.014 in.
0.28 – 0.36 mm
0.014 – 0.020 in.
0.36 – 0.51 mm
0.004 – 0.008 in.
0.10 – 0.20 mm
0.002 – 0.005 in.
0.05 – 0.13 mm
0.005 – 0.007 in.
0.13 – 0.18 mm
4606
0.003 – 0.006 in.
0.08 – 0.15 mm
0.009 – 0.012 in.
0.23 – 0.30 mm
0.012 – 0.019 in.
0.30 – 0.48 mm
0.005 – 0.011 in.
0.13 – 0.28 mm
0.002 – 0.005 in.
0.05 – 0.13 mm
0.006 – 0.008 in.
0.15 – 0.20 mm
4610
0.003 – 0.006 in.
0.08 – 0.15 mm
0.014 – 0.017 in.
0.36 – 0.43 mm
0.017 – 0.024 in.
0.43 – 0.61 mm
0.005 – 0.011 in.
0.13 – 0.28 mm
0.002 – 0.005 in.
0.05 – 0.13 mm
0.006 – 0.008 in.
0.15 – 0.20 mm
6009
0.002 – 0.005 in.
0.05 – 0.013 mm
0.018 – 0.022 in.
0.46 – 0.56 mm
0.022 – 0.025 in.
0.56 – 0.64 mm
0.015 – 0.016 in.
0.38 – 0.41 mm
0.004 – 0.007 in
0.10 – 0.18 mm
0.007 – 0.009 in.
0.18 – 0.23 mm
6015
0.006 – 0.009 in.
0.05 – 0.013 mm
0.020 – 0.024 in.
0.51 – 0.61 mm
0.026 – 0.033 in.
0.61 – 0.69 mm
0.012 – 0.015 in.
0.38 – 0.41 mm
0.004 – 0.007 in.
0.10 – 0.18 mm
0.009 – 0.011 in.
0.18 – 0.23 mm
ASSEMBLY CLEARANCES
