Cutaway Drawings and Parts Lists
Operator’s Manual 2010 Rev B p/n 2010
PARTS LIST FOR QX-6000 SERIES BLOWERS
ITEM
NO.
PART DESCRIPTION QTY
1
HOUSING
1
2
DRIVEN ROTOR
1
3
DRIVE ROTOR
1
4
ENDPLATE
2
5
DRIVE COVER
1
6
GEAR END COVER
1
7
GEAR ASSEMBLY
1
8
GEAR SPACER
1
9
TIMING GEAR KEY
2
10
BALL BEARING
2
12
CYLINDER BEARING
2
13
SEAL ASSEMBLY
4
14
DRIVE COLLAR
1
15
OIL SLINGER
1
16
SET SCREW
2
17
OIL SLINGER SPACER
1
ITEM
NO.
PART DESCRIPTION QTY
18
LIP SEAL
1
19
SEAL WEAR RING
1
20
BEARING SHIM
–
21
HOUSING SHIM
–
22
ORING
2
23
DOWEL PIN
6
24
CAP SCREW
16
25
CAP SCREW
20
26
ROTOR WASHER
3
27
FLAT CAP SCREW
3
28
SOCKET PIPE PLUG
8
29
HEX PIPE PLUG
6
30
OIL SIGHT GLASS
4
31
OIL DRAIN PLUG
2
32
WASHER
8
33
CAP SCREW
8
