Cutaway Drawings and Parts Lists
Operator’s Manual 2010 Rev B p/n 2010
PARTS LIST FOR QX-3200 AND QX-4600 SERIES BLOWERS
ITEM
NO.
PART DESCRIPTION QTY
1 HOUSING
1
2 DRIVE ROTOR 1
3 DRIVEN ROTOR 1
4 ENDPLATE 1
5 DRIVE COVER 1
6 GEAR END COVER 1
7 GEAR ASSEMBLY 1
8 GEAR SPACER 1
9 GEAR KEY 2
10 BALL BEARING 2
12 CYLINDER BEARING 2
13 SEAL ASSEMBLY 4
14 DRIVE COLLAR 1
15 OIL SLINGER 1
16 LIP SEAL 1
17 SEAL WEAR RING
1
ITEM
NO.
PART DESCRIPTION QTY
18 BEARING SHIM
–
19 HOUSING SHIM –
20 O-RING 1
21 DOWEL PIN 4
22 CAP SCREW 26
23 ROTOR WASHER 3
24 FLAT CAP SCREW 3
25 OIL SIGHT GLASS 4
26 HEX PIPE PLUG 2
27 OIL DRAIN PLUG 4
28 SOCKET PIPE PLUG 8
29 SQUARE PIPE PLUG 2
30 SET SCREW 2
31 WASHER 4
32 CAP SCREW
4
