700H1471 Rev 2
Materials of Construction
Materials of construction of the external surface of the unit are: painted steel;
painted cast iron; painted aluminum; zinc plated steel.
Materials of construction of the wetted parts are: cast iron; steel; zinc plated steel;
300 series stainless steel; carbon; fluorocarbon; buna; 400 series stainless steel;
aluminum; phenolic; thermoplastic polyester; polybutylene terephthalate and copper.
Repair and Maintenance
Contact the place of purchase for warranty repair and maintenance
Specific Conditions of Use
1. Consult the manufacturer if dimensional information on the flameproof joints
is necessary.
2. ISO Class 8.8, M6 hex-head screws (Yield Stress 640 MPa) shall be used to
replace the FR700V Series terminal cover fasteners.
3. ISO Class 10.9, M8 hex-head screws (Yield Stress 940 MPa) shall be used to
replace the FR700V Series motor tie-rod fasteners.
4. An electrically conductive hose and nozzle must be used with flammable liquids.
To minimize static electricity buildup, always keep the nozzle in contact with the
container being filled during the fueling process.
Installation
Pump must be installed in compliance
with EN 60079-14 or IEC 60079-14,
as applicable.
Certificates for Compliance of Safety have
been obtained for the following agencies
Tuthill Corporation
8825 Aviation Drive
Fort Wayne, Indiana 46809 USA
P (800) 634-2695
(+01) 260-747-7524
F (800) 866-4681
tuthill.com | fillrite.com | sotera.com
for products sold outside the US and Canada. Please refer to the tag on your
particular product for its particular compliance data.
The following standards were used to show compliance in the European Union:
EN IEC 60079-0:2018, Ed 7 “Explosive atmospheres
– Part 0: Equipment –
General requirements”
EN 60079-1:2014, Ed 7 “Explosive atmospheres – Part 1: Equipment protection
by flameproof enclosures “d””
EN ISO 80079-36:2016, Ed 1 “Explosive atmospheres – Part 36: Non-electrical
equipment for explosive atmospheres – Basic method and requirements”
EN ISO 80079-37:2016, Ed 1 “Explosive atmospheres – Part 37: Non-electrical
equipment for explosive atmospheres – Non electrical type of protection
constructional safety “c”, control of ignition source “b”, liquid immersion “k””
Directive 2014/34/EU – Equipment and protective systems intended for use in
potentially explosive atmospheres.
Directive 2011/65/EU – Restrictions of the use of certain hazardous substances in
electrical and electronic equipment.
The following standards were used to show compliance for IECEx certification:
IEC 60079-0:2017, Ed 7
IEC 60079-1:2014, Ed 7
ATTENTION!
The following information is for suffix “E” pumps and meters (designed for use outside the United States and Canada)! Refer to the information label applied to your pump
to see if it is applicable.
2809
II 2 G
Ex db h IIA T4 Gb
FM19ATEX0019X
IECEx FMG19.0013X
Ex db IIA T4 Gb
