Operator’s Manual 1808 022016 ENG
25
GENERAL
The graphics on the following pages and their parts
lists cove r all parts in the K D-30 and K D-5 0 pumps,
any of which are ava ilable as spare parts. Always
include the model and serial number of the pump
when ordering parts.
SPARE PARTS
Recommended spare parts are indicated on the
parts list by an asterisk, which include gaskets,
O-rings, shaft seal, and discharge va lve s. The
recommended spare parts are intended to support
the pump until a more extensive stock of spare
parts can be deve loped based upon usage data
as parts are replaced. The number of pumps in
operation plus the degree of importance of keeping
the pumps in ready condition are factors to be
considered when deve loping a stock of spare
parts. Maintain an adequate supply of AX Oil and
Loctite 5 15 , and have a va cuum gauge ava ilable
for checking pump performance.
10
REPLACEMENT PARTS
