Replacem ent Parts
KD- 30A/5 0 B PARTS LIST
(Manufacture date after 9/23/2016)
ITEM
NO.
DESCRIPTION Q TY
1 Cylinder 1
2 Head, Open & Closed End 2
3
Housing, Shaft Seal &
B earing
1
4 Cap, Closed End 1
5 Cov er, Cylinder 1
6** Gasket, Cylinder Cove r 1
7 Cam, Open End (Heavy) 1
8 Cam, Closed End 1
9 Piston 2
10 Slidepin 2
11 Shaft 1
12* * Discharge V alve 2
13 Plate, V alve Hold Down 2
14 B earing, Head 2
15
Spacer, B earing, Open
Head
3
16 B earing Assmbly, Out. 1
16A B all B earing w/ ID Taper 1
16B B earing Adapter 1
17 * * Shaft Seal, 3/4 V iton 1
18* * Retaining Ring, .7 5 Ext. 1
19* * O-Ring, 2-27 B una-N 2
20 K ey, Cam, Woodruff 13 2
21
K ey, Drive , 3/16 sq. x
1-1/4 lg.
1
22 Dowel Pin 1/8 dia. x 1/2 lg. 1
23 Dowel Pin 5 /16 dia. x 7 /8 lg. 4
24
Hex Head Cap Screw,
5 /16-18 x 3/4 lg.
36
25
Hex Head Cap Screw,
5 /16-18 x 7 /8 lg.
10
26
Socket Head Cap Screw,
5 /16-18 x 7 /8 lg.
1
27
Socket Head Cap Screw,
5 /16-18 x 5 /8 lg.
6
28
Pipe Plug, Hex Sock,
1/8 NPT
2
ITEM
NO.
DESCRIPTION Q TY
29 Gas B allast V alve 1
30 Drain Cock, Oil, 1/4 NPT 1
31*
Discharge Separator Tank
Assy.
1
32 1/4 NPT Close Nipple 1
33
1/4 NPT Elbow 1
34
Pump Sheave
1
35**
Solenoid Valve 240/480V
1
* Refer to Oil Mist Eliminator manual, 1855-1
* * Item not shown
To Next Page
