Tuthill KINNEY KD Series User Manual

Operator’s Manual 1808 022016 ENG
31
10
Replacem ent Parts
KD- 5 0 B PARTS LIST
(Manufacture date before 9/23/2016)
ITEM
NO.
DESCRIPTION Q TY
1 Cylinder 1
2 Head, Open & Closed End 2
3
Housing, Shaft Seal &
B earing
1
4 Cap, Closed End 1
5 Cove r, Cylinder 1
6*/* * Gasket, Cylinder Cove r 1
7 Cam, Open End (Heavy) 1
8 Cam, Closed End 1
9 Piston 2
10 Slidepin 2
11 Shaft 1
12* * Discharge V alve 2
13 Plate, V alve Hold Down 2
14 B earing, Head 2
15
Spacer, B earing, Open
Head
1
16 B earing Assmbly, Out. 1
16A B all B earing w/ ID Taper 1
16B B earing Adapter 1
17 * * Shaft Seal, 3/4 V iton 1
18* * Retaining Ring, .7 5 Ext. 1
19* * O-Ring, 2-27 B una-N 2
20 K ey, Cam, Woodruff 13 2
21
K ey, Drive , 3/16 sq. x
1-1/4 lg.
1
22 Dowel Pin 1/8 dia. x 1/2 lg. 1
23 Dowel Pin 5 /16 dia. x 7 /8 lg. 4
24
Hex Head Cap Screw,
5 /16-18 x 3/4 lg.
36
25
Hex Head Cap Screw,
5 /16-18 x 7 /8 lg.
10
26
Socket Head Cap Screw,
5 /16-18 x 7 /8 lg.
1
27
Socket Head Cap Screw,
5 /16-18 x 5 /8 lg.
6
28
Pipe Plug, Hex Sock,
1/8 NPT
2
ITEM
NO.
DESCRIPTION Q TY
29 Gas B allast V alve 1
30 Drain Cock, Oil, 1/4 NPT 1
31
Discharge Separator Tank
Assy.
1
31A* * Flange Gasket 1
31B Oil Mist Eliminator Element 1
31D* * Check Disc, V iton 1
31E Dispersion Screen 1
31F Sightglass, 2" NPT 1
31G Oil Drain Cock, 1/2 NPT 1
31H* Seal Nut, 1-1/2 NPT 1
31I* Reinforcing Plate 1
32* Solenoid V alve 240/480V 1
33* Pump Sheave 1
34*
V -B elt 3V X37 5 (w/ FR 5 6
motor)
1
34*
V -B elt 3V X47 0 (w/ FR145 T
motor)
1
* Item Not Shown
* * Item included in repair/maintenance kit
