In Dual PIP mode, A, B and Z are all definable (if Lock&Mix is active) – thus 3
audio sources will be mixed together. The mixing is done via addition, so
volume levels should be borne in mind.
This single volume / mute selection controls all 8 audio channels being
processed for this window. (Adjust audio allows individual selection of volume
on a per-source basis.)
9.12.3 Extra item in Adjust sources
.
.
.
These 8 menu items control the selection of the audio source that is
associated with each video source (when used in AFV – ‘audio follow video’
mode). Note that since 8 audio channels are processed for each video
source, you have 8 stereo audio channels that can be assigned. These are
processed in parallel by the unit – the 8 are never inter-mixed.
SDI inputs default so that their 8 associated audio channels are the audio
channels embedded within them. Non-SDI inputs all default to AES1 to AES
8 being their audio sources.
The above menu therefore lets you select DVI-I1 to be AES1, DVI-I2 to be
AES2, etc.
9.12.4 Adjust audio
This menu controls which audio source is being altered, using the following
sub-menus:
This controls the volume level – volume levels can be both positive and
negative.
Adjust sources
Audio channel 8 [AES8 ]
Adjust audio
Volume trim [0] dB
Adjust audio
Source to adj: [AES1]
Adjust sources
Audio channel 1 [AES1 ]
