TVLogic F-7HS - BUTTON FUNCTIONS; MENU <EXIT> BUTTON; KNOB BUTTON

24
FHD Hight Bright Field Monitor
06 BUTTON FUNCTIONS
MENU <EXIT> BUTTON / KNOB BUTTON
SDI A
HDMI
1920 x 1080 50p
• F-7HS unit is capable of processing SDI/
HDMI Input Signal.
1. Press the [MENU<EXIT>] button on the top of
the monitor for more than 2 seconds and
activate the input selection menu as shown
above.
2. The resolution of the input video is displayed
on the bottom of the OSD screen.
3. Press the [MENU<EXIT>] button again to remove
the OSD menu from display.
* If no image displays after selecting the desired
input mode, check and make sure that your
connection is not lost or disconnected.
• F-7HS monitor supports the HOT KEY input.
1. Press the [Knob] button on the top of the
monitor for more than 2 seconds and activate
the settings adjustment menu as shown above.
Move to a desired menu with the Knob and
press the Knob to select.
The mode changes in this order: VOLUME →
BRIGHTNESS → CONTRST → CHROMA →
SHARPNESS → PEAKING BOOST
2. Adjust the set value by rotating the Knob.
3. Press the [MENU<EXIT>] on the top of the
monitor again to remove the OSD menu from
display.
[1] MENU <EXIT> BUTTON
VOLUME
+ 15
[2] KNOB BUTTON
BRIGHTNESS
+ 0
CONTRAST
+ 0
CHROMA
+ 0
SHARPNESS
+ 0
PEAKING BOOST
+ 0
