03 CONTROLS & FUNCTIONS
7
FHD Hight Bright Field Monitor
F-7HS ALL PART
PHONEJACK
HDMI OUT
HDMI IN
KNOB
MENU<EXIT>
SOURCE
USB
DC POWER
/TALLY
SDI OUT
REAR TALLY
SDI IN
POWER BUTTON
FUNCTION/
FUNCTION SELECT
