FHD Hight Bright Field Monitor
* The specication above may be changed without notice.
Specications F-7HS
LCD
Size 7”
Resolution 1920×1200 (16:10)
Pixel Pitch 0.07875(H) X 0.07875(V) mm
Color Depth 1.073B Colors (10 bit)
Viewing Angle 160°(H) / 160°(V)
Luminance of white
1800 nits(Max)
Contrast Ratio 1200 : 1
Display Area 151.2(H) X 94.5(V) mm
Input
1 X HDMI HDMI Input
1 X BNC 3G/HD/SD SDI Input
Output
1 X HDMI HDMI Output (HDMI loop out, SDI-to-HDMI Conversion output)
1 X BNC 3G/HD/SD SDI Output (SDI loop out, HDMI-to-SDI Conversion output)
Input Signal
3G-SDI 2.970 Gb/s
HD-SDI 1.485 Gb/s
SD-SDI 270 Mb/s
HDMI 480i / 480p / 576i / 576p / 720p / 1080i / 1080p
SDI Input Signal
Formats
SMPTE ST-425M-A/B
1080p (60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF)
1080i (60/59.94/50)
SMPTE ST-274M
1080i (60/59.94/50)
1080p (30/29.97/25/24/24sF/23.98/23.98sF)
SMPTE ST-296M 720p (60/59.94/50)
SMPTE ST-125M 480i (59.94)
ITU-R BT.656 576i (50)
Update 1 x USB USB A type, Firmware Upgrade
Audio In SDI Embedded Audio (Group, Ch Selectable)
Audio Out External Output Port (3.5m Phone Jack)
Power DC 6V ~ 34V
Power Consumption (Approx.) 21W(Max)
Operating Temperature 0℃ to 40℃ (32
℉
to 104
℉
)
Storage Temperature -20℃ to 60℃ (-4
℉
to 140
℉
)
Dimensions
Main Body 211 x 125 x 28.3mm (8.3 x 4.95 x 1.11 inch)
Shipping Box 290 X 158 X 83mm (11.42 X 6.22 X 3.27 inch)
Weight 0.76kg / 1.67lbs
Basic Accessories D-Tap-C Cable, Camera Mount
Optional Accessories
External Acrylic Protector, Sun Hood, D-Tap Power Cable, Battery Bracket,
V-Mount Battery Bracket, Anton-Bauer(Gold) Battery Bracket, Carrying Case,
DC Adapter, HDMI Bracket

TVLogic F-7HS Specifications

General

Brand	TVLogic
Model	F-7HS
Category	Monitor
Language	English
