03 CONTROLS & FUNCTIONS
8
FHD Hight Bright Field Monitor
TOP / FRONT
• [MENU/EXIT/SOURCE] Button
- Used to activate the OSD menu.
- When the OSD menu is activated, press this
button to exit from the menu.
- Press the button for more than 2 seconds to
activate Input Select menu. (SDI, HDMI)
- Use the [ENCODER] Knob to change the Input
Signal.
• [UP/DOWN/ENTER] Knob
- Used to move within the menu when OSD menu
is activated, and is also used to decrease or
increase the value of the selected feature.
- Press the knob to select the main menu and the
sub menus.
- Press the button for more than 2 seconds to
activate the HOT Key menu.
(VOLUME / BRIGHTNESS / CONTRAST / CHROMA
/ SHAPRNESS / PEAKING BOOST)
• [F1]~[F3] Button
- Press the button for less than 2 seconds to
activate the function.
- Press the button for more than 2 seconds to
activate Function Select menu.
(Scan, Aspect, H/V delay, etc.)
- Press the button for more than 2 seconds to
indicate previously selected function.
- Use the Knob to change the function.
